Wire shelving is the specification for natural foods, produce adjacencies, and any category where ventilation, visibility-through, and sanitation compliance matter more than a solid surface.

Drop-In Wire Shelf (DW): clips into standard Lozier uprights, flat or angled position, 1in slot increments
Reversible Wire Shelf (RBS): reverses for two angle options from a single shelf without removal
Four Post Wire Shelving Unit (FPW): widths 2-4ft, depths 14-24in, heights 54-86in, 550 lbs per shelf, 1,500 lbs per unit
NSF certified in BCP (Chrome Plated) and CHR (Charcoal Black) finishes for food-safe environments
Wire Baskets and Snack Shelves available for loose-item and gravity-feed presentations
Free-Standing Wire Fronts (FSF): 48in wide, 6in high, for shelf-front containment of roll or gravity-feed items
Compatible with standard Lozier uprights using the same clip mechanism as solid TL and DL shelves

Compatibility: Lozier drop-in wire shelves (DW/RBS) clip into standard Lozier uprights at any slot position using the same clip mechanism as solid shelves, and can be mixed with solid shelves on the same uprite. Four Post Wire units are freestanding and do not require Lozier uprights. Wire Baskets and Snack Shelves use standard bracket mounting. For food-service and produce applications, specify BCP (Chrome Plated) or CHR (Charcoal Black) NSF-certified finishes and confirm with the local health department before installation.

Designed for: Natural foods, organic and specialty grocery sections, produce adjacencies, health and beauty, vitamins and supplements, deli perimeter, and any department where air circulation, product visibility, or food-safe surface requirements govern fixture selection.

Configuration Reference

Lozier wire shelves are available in Tilt-In (TL) and Drop-In (DL) mounting styles and must match the mounting style already established in each section. Mixing TL and DL within a single section requires a full rail replacement, which adds cost and labor. Confirm the existing rail configuration before specifying wire shelf style.

Standard finishes for Lozier wire shelves are Platinum (PLT) and Charcoal (CHR). Optional Catalog Colors require an 8 to 10 week lead time from the Lozier distribution center. For remodel projects with a defined completion date, confirm finish availability at the time of order, not at the time of planning.

Wire shelf depth must match or exceed the Base Bracket depth in the same section to maintain structural alignment and rated load capacity. A 19-inch wire shelf installed over a 22-inch (22D) Base Bracket creates an unsupported rear gap that affects product placement and can compromise shelf stability under load.

Lozier wire shelves use the same one-inch slotted Uprite pattern as solid TL and DL shelves, allowing shelf height adjustment in one-inch increments without tools. This compatibility means wire shelves can be added to or substituted within any standard Lozier gondola section without modifying the Uprite.

Frequently Asked Questions

What is the difference between a Tilt-In and a Drop-In Lozier wire shelf?

A Tilt-In (TL) shelf engages the Uprite slot from an angle above and pivots down to lock into position, while a Drop-In (DL) shelf slides straight down into the slot from above. The two styles use different rail hardware and are not interchangeable within the same gondola section. Check your existing Top Rail and Center Rail style before ordering.

How do I know which wire shelf depth to order for my store?

Match wire shelf depth to your product category and Base Bracket depth. Health and beauty runs typically use 13-inch shelves, drug and convenience store center aisle runs use 16-inch, and grocery or general merchandise runs use 19-inch or 22-inch depths. The wire shelf depth should always match the Base Bracket depth installed in that section.

Lozier wire shelf finish codes PLT CHR compatibility

Platinum (PLT) and Charcoal (CHR) are the two standard Lozier finishes available with the shortest lead times from Lozier distribution centers. Wire shelves ordered in Optional Catalog Colors carry an 8 to 10 week production lead time. Always specify the finish code that matches your existing Uprite and rail finish to maintain a consistent installation.

Lozier wire shelf load capacity vs solid shelf

Wire shelves carry a different rated load capacity than solid shelves of the same depth and width. For heavy product categories such as canned goods, bottled beverages, or bulk items, verify the wire shelf load rating against Lozier published specifications before substituting wire for solid. Overloading a wire shelf beyond its rated capacity can cause permanent shelf deformation.
